zhejiang tongxiang jingtong floor storage sorting and loading -至尊国际

our customer is a modern digital wall and floor enterprise integrating r&d, production and sales of the lvt floor, wpc floor, spar floor and soft spar floor. its businesses cover more than 40 countries and regions worldwide with the annual output of the base floor reaching 45 million square meters. it has a 3,500-square-meter warehouse that can store 5,000 pallets of products, which cannot meet the growing order demand. also, there is low efficiency in finding goods for loading according to the order due to the mixed storage of various products in the warehouse.

solutions:
hence, what the customer needs is to increase the storage quantity, improve the sorting and distribution efficiency according to the order, and realize the integration of warehousing and loading. 3 sets of aerial sorting robots, 2 sets of drum-type rgvs, and 2 sets of vehicle platforms are deployed according to the customer's plant conditions; and the warehouse area is divided for stacking according to the size of product trays, upgrading the maximum storage quantity to reach 8,000 pallets.

1. storage capacity is increased by 60%
forklift access is not required in the aerial sorting intelligent warehouse, with the storage height increased to 4.5m (the original storage height is 3m on average).

2. the warehousing efficiency is increased by 2 times with the ex-warehouse efficiency increased by 15 times.
multiple robots working together in the warehouse can achieve 1,000 pallets in and out of the warehouse per day in combination with the self-developed intelligent scheduling and sorting system by jinshi robot.

3. intelligent typesetting, flexible loading
the ex-warehouse code is automatically placed on the loading platform to achieve fast loading using the latest flexible loading platform developed by jinshi robot together with the stacking algorithm.
